Brand Name : BEFANBY
Model Number : KPX
Certification : CE,SGS,ISO9001
Place of Origin : Henan,China
MOQ : 1 set/sets
Price : Negotiation
Payment Terms : L/C,T/T,Western Union
Supply Ability : 1500 set/sets, per year
Delivery Time : 20-30 days as usual delivery
Packaging Details : The motorized slab trolley will be packed by the tarp, the parts will be shipped in the high quality wooden case.
Material : Q235
Color : Customized
Application : Industrial field,motorized slab transfer
Running speed : 0-20m/min
Running distance : 60m, customized on demand
Warranty : 24 months
Port : Qingdao/Tianjin/Shanghai
Load capacity : 1-100 Ton Payload
Power supply : Battery Powered
Operation type : Hand pendant + remote control
Advantage : More than 19 years' experience for motorized slab transfer
Option Power : cable power supply, trolly line, low voltage rail, diesel, etc.
The rail transfer cart uses environmentally friendly batteries as a power source, has a long endurance and is flexible in operation. It can be used in turning situations.
The transfer cart runs smoothly along the preset track and is suitable for material transportation between workshops, high-temperature situations and within large factories. It is especially suitable for heavy workpieces, large-scale transfer and other operational needs.
We customize this equipment according to the actual needs of customers, and can provide one-stop services in product design, production, installation, after-sales, etc., eliminating the intermediate links. We support non-standard customization, including personalized adjustment of parameters such as load capacity, table size, functional structure (such as adding lifting, rollers, rollers, V-frames, etc.), to ensure seamless connection between equipment and process.
Model | KPX-10t | KPX-16t | KPX-25t | KPX-30t | KPX-40t | KPX-50t | KPX-63t | KPX-80t | KPX-100t | KPX-150t | |
Rated Load | 10 | 16 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
Table size | Length(L) | 3600 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
Width(W) | 2000 | 2000 | 2200 | 2200 | 2500 | 2500 | 2500 | 2600 | 2800 | 3000 | |
Height(H) | 500 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 | |
Wheel Base | 2600 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
Rail Inner Gauage | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
Wheel Diameter | 300 | 350 | 400 | 400 | 500 | 500 | 600 | 600 | 600 | 600 | |
Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
Ground Clearance | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
Running Speed | 25 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 18 | |
Motor Power | 2 | 2.2 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | 15 | |
Battery Capacity | 160 | 180 | 250 | 250 | 300 | 330 | 400 | 400 | 440 | 600 | |
Battery Voltage | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | |
Max Wheel Load | 42.6 | 64.5 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
Reference Weight | 4.2 | 5.5 | 6.5 | 6.8 | 7.6 | 8 | 10.8 | 12.8 | 14.6 | 26.8 |
All can be customized as per customers’ requirement.And BEFANBY business is meeting your business need, hope our professional team can help you well with rich experience.
battery powered transfer
cart rail power supply trolley line motorized rail cart cable power supply
Advantages
✔ Higher load capacity – Depending on the design, it can carry from 1 ton to more than 100 tons.
✔ Precise movement – Fixed tracks prevent deviation and ensure accurate positioning.
✔ Low maintenance costs – Simple structure and optional custom accessories.
✔ Customizable – Can be installed with turntable, lifting structure or V-frame device.
